Parameter type |
Parameter |
Parameter type |
Parameter |
Production dimension (L/W/H *inch) |
85.5/35/38.8 |
Splitting stroke Length (inch) |
26.4 |
Net weight (KG) |
205 |
Working pressure |
20MP-32MP adjustable |
Packing size (inch) |
47.4/22.2/33 |
OEM |
Acceptable |
Total weight of packing (KG) |
223 |
Engine brand |
Briggs &Stratton |
Horizontal/vertical |
Horizontal and vertical |
Engine type |
Air-cool and four-stroke gasoline engine, OHV |
Splitting method (optional) |
2 ways/4 ways |
Engine displacement |
6.5P 208CC |
Cycle |
11S |
Axial direction of engine |
Horizontal axis |
Model/flow L/min for oil pump |
CBNA-13/1.8D |
Start engine |
Electric/recoil |
Control valve |
26.4GAL three-position automatic return |
Rated torque* (N.m@3060rpm) |
12.9 |
Max. tonnage |
25T |
Cylinder body |
Single cylinder with sleeve made of cast iron |
Hydraulic oil No. |
46# |
Engine oil tank capacity |
0.82GAL |
Filter |
Available |
Cylinder diameter (inch) |
2.7 |
Wheel tires |
4.8-8 |
Machine Oil volume |
0.16GAL |
Traction |
American 2*2 trailer ball cover |
Engine Stroke (inch) |
2.2 |
Min. hydraulic oil level |
2.38GAL |
Engine Net weight (LBS) |
7.26 |
Max. hydraulic oil level |
4GAL |
Engine specification (L*W*Hinch) |
12.6*14.8*13.6 |
Inner diameter of oil cylinder (inch) |
4 |
|
|
