Parameter type |
Parameter |
Parameter type |
Parameter |
Production dimension (L/W/H *inch) |
110.2/56.2/46 |
Hand-operated support leg |
1.5T |
Net weight (KG) |
295 |
Wooden bracket |
there are |
Packing size (inch) |
59/26/34.6 |
Working pressure |
20MP-32MP can be adjusted |
Total weight of packing (KG) |
330 |
OEM |
Acceptable |
Wooden bracket |
Hydraulic lifting log pallet |
Customer warranty |
1year |
Splitting method |
Hydraulically 2 ways/4 way |
Engine brand |
RATO |
Cycle |
10S |
Engine type |
Air-cool and four-stroke gasoline engine, OHV |
Oil pump model/flow L/min |
CBNA-13/1.8D |
Engine displacement |
7P 212CC |
Control valve(1) |
26.4GAL three-position automatic return |
Axial direction of engine |
Horizontal axis |
Control valve(2) |
10.5GAL three-position automatic return |
Start engine |
Electric/recoil |
Max. tonnage |
28T |
Rated torque* (N.m@3060rpm) |
12 |
Hydraulic oil No. |
46# |
Cylinder body |
Single cylinder with sleeve made of cast iron |
Tires |
4.80-8 |
Engine oil tank capacity |
0.83GAL |
Min. oil level of hydraulic oil |
4.2GAL |
Cylinder diameter (inch) |
2.7 |
Max. oil level of hydraulic oil |
5.8GAL |
Machine Oil volume |
0.15GAL |
Inner diameter of cylinder (inch) |
3.9 |
Engine Stroke (inch) |
2.1 |
Splitting stroke Length (inch) |
27.6 |
Engine Net weight (LBS) |
7.26 |
Traction |
American 2*2 trailer ball cover |
Engine specification (L*W*Hinch) |
15.3*12.5*13.5 |
