Parameter type |
Parameter |
Parameter type |
Parameter |
Production dimension (L/W/H *inch) |
86.6/27.1/35 |
Working pressure |
20MP-32MP can be adjusted |
Net weight (KG) |
150 |
OEM |
Acceptable |
Packing size (inch) |
51.5/23/25 |
Customer warranty |
1year |
Total weight of packing (KG) |
174 |
Engine brand |
RATO |
Horizontal/Vertical |
Horizontal |
Engine type |
Air-cool and four-stroke gasoline engine, OHV |
Splitting method (optional) |
2 ways/4 ways |
Engine displacement |
7P 202CC |
Cycle |
8S |
Axial direction of engine |
Horizontal axis |
Oil pump model/flow L/min |
CBNA-13/1.8D |
Start engine |
Electric/recoil |
Control valve |
26.4GAL three-position automatic return |
Rated torque* (N.m@3060rpm) |
12 |
Max. tonnage |
18T |
Cylinder body |
Single cylinder with sleeve made of cast iron |
Hydraulic oil No. |
46# |
Engine oil tank capacity |
0.83GAL |
Tires |
3.50-5 |
Cylinder diameter (inch) |
2.7 |
Min. oil level of hydraulic oil |
3.1GAL |
Machine Oil volume |
0.15GAL |
Max. oil level of hydraulic oil |
4.2GAL |
Engine Stroke (inch) |
2.1 |
Inner diameter of cylinder (inch) |
3.15 |
Engine Net weight (LBS) |
7.26 |
Splitting stroke Length (inch) |
26.7 |
Engine specification (L*W*Hinch) |
15.3*12.5*13.5 |
